Drilling Insert

T-Drill Insert SPMG

ORDERING Code d t r D1 Drill Dia Grade
AP0025 AP0525 AP5025
SPMG050204-TT 5.0 2.38 0.4 2.25 12.5-15.0
SPMG060204-TT 6.0 2.38 0.4 2.61 15.5-21.5
SPMG07T308-TT 7.94 3.97 0.8 2.85 22.0-27.5
SPMG090408-TT 9.8 4.3 0.8 4.05 28.0-33.0
SPMG110408-TT 11.5 4.8 0.8 4.45 34.0-41.0
SPMG140512-TT 14.3 5.2 1.2 5.75 42.0-50.0

U-Drill Insert

WCGX

ORDERING Code d t R D1 l Grade
AP0025 AP0525 AP5025
WCGX030204-TT 5.56 2.38 0.4 2.55 3.8
WCGX030208-TT 5.56 2.38 0.4 2.55 3.8
WCGX040204-TT 6.35 2.38 0.4 2.8 4.3
WCGX040208-TT 6.35 2.38 0.8 2.8 4.3
WCGX050308-TT 7.94 3.18 0.8 3.4 5.4
WCGX06T308-TT 9.52 3.97 0.8 4.4 6.5
WCGX080408-TT 12.7 4.76 0.8 5.5 8.7
WCGX080412-TT 12.7 4.76 1.2 5.5 8.7
